1.25G BIDI SFP Tx1490/Rx1550nm 80km Simplex LC Connectors for Cisco
Features
Ø Dual data-rate of 1.25Gbps/1.063Gbps operation
Ø 1490nm DFB laser and PIN photodetector for 80km transmission
Ø Compliant with SFP MSA and SFF-8472 with simplex LC receptacle
Ø Digital Diagnostic Monitoring:Internal Calibration or External
Calibration
Ø Compatible with SONET OC-24-LR-1
Ø Compatible with RoHS
Ø +3.3V single power supply
Ø Operating case temperature range:
0 °C to +70 °C (Commercial)
-40 °C to +85 °C (Industrial)
Applications
Ø Gigabit Ethernet
Ø Fiber Channel
Ø Switch to Switch interface
Ø Switched backplane applications
Ø Router/Server interface
Ø Other optical transmission systems
Description
Linkopto SFP-BIDI transceivers are high performance, cost effective
modules supporting dual data-rate of
1.25Gbps/1.0625Gbps and 80km transmission distance with SMF.
The SFP transceiver consists of three sections: a FP laser
transmitter, a PIN photodiode integrated with a trans-impedance
preamplifier (TIA) and MCU control unit. All modules satisfy class
I laser safety requirements.
Our transceivers are compatible with SFP Multi-Source Agreement (MSA)
and SFF-8472. For further information, please refer to SFP MSA.
Quality Control
Package
Related Product List
| Item No. | Description |
|
| SFP-BX-U-10 | 1.25G Tx1310nm/Rx1550nm 10km DOM BiDi SFP LC |
| SFP-BX-D-10 | 1.25G Tx1550nm/Rx1310nm 10km DOM BiDi SFP LC |
| SFP-2GBX-U-S20 | 2.5G Tx1310nm/Rx1550nm 20km DOM BiDi SFP SC |
| SFP-2GBX-D-S20 | 2.5G Tx1550nm/Rx1310nm 20km DOM BiDi SFP SC |
| SFP-BX-U-S40 | 1.25G Tx1310nm/Rx1550nm 40km DOM BiDi SFP SC |
| SFP-BX-D-S40 | 1.25G Tx1550nm/Rx1310nm 40km DOM BiDi SFP SC |
| SFP-BX-U-S80 | 1.25G Tx1490nm/Rx1550nm 80km DOM BiDi SFP SC |
| SFP-BX-D-S80 | 1.25G Tx1550nm/Rx1490nm 80km DOM BiDi SFP SC |
| SFP-BX-U-L120 | 1.25G Tx1490nm/Rx1550nm 120km DOM BiDi SFP LC |
| SFP-BX-D-L120 | 1.25G Tx1550nm/Rx1490nm 120km DOM BiDi SFP LC |
| SFP-10G-SR | Multimode Dual LC 10G 850nm 300m SR SFP+ |
| XFP-10G-LR | Dual LC 10G 1310nm 20km LR XFP+ |
| SFP-10G-ER | Dual LC 10G 1550nm 40km ER SFP+ |
| SFP-10G-ZR | Dual LC 10G 1550nm 80km ZR SFP+ |
| SFP-10G-ZR100 | Dual LC 10G 1550nm 100km ZR SFP+ |
| SFP/SFP+ Compatible Cisco ASR 1001-X 1002-X
Zyxel XGS-2210-28 and zyxel XGS-4600-32 |
| EPON OLT PX20+ | 1.25G/1.25G Tx1490nm/Rx1310nm EPON OLT SFP PX20+
Compatible Chinese OLT
|
