    80km 10G SFP+ CWDM Transceiver Duplex LC With 1270 - 1610 Wavelength

    Ask Lasest Price
    Brand Name : Linkopto , or OEM
    Model Number : LSCxxX-3LCD80
    Certification : CE, FCC, ROHS, TUV, ISO9001
    Price : Get latest price
    Payment Terms : T/T, WU, PayPal, Moneygram, L/C
    Supply Ability : 20,000pcs per week
    Delivery Time : 1~3 working days
    • Product Details
    • Company Profile

    80km 10G SFP+ CWDM Transceiver Duplex LC With 1270 - 1610 Wavelength

    PN: LSCxxX-3LCD80
    10G CWDM SFP+ Transceiver 10G SFP+ CWDM 1270~1610 80km Duplex LC

    Features

    1. Up to 11.1Gbps Data Links
    2. Up to 80km transmission on SMF
    3. ​Power dissipation < 1.5W
    4. ​CWDM EML Laser and APD receiver

    5. ​Metal enclosure, for lower EMI

    6. ​2-wire interface with integrated Digital Diagnostic monitoring
    7. ​Hot-pluggable SFP+ footprint
    8. ​Specifications compliant with SFF 8472
    9. ​Compliant with SFP+ MSA with LC connector
    10. ​Single 3.3V power supply
    11. ​Case operating temperature range:0°C to 70°C

    Applications

    1. 10GBASE-ZR/ZW

    2. 10G Ethernet

    Standard

    1. Compliant to 802.3ae 10GBASE-ZR/EW

    2. Compliant to SFF-8431

    3. RoHS Compliant

    Related Prodcuts


    Item No.Description
    SFP-BX-U-101.25G Tx1310nm/Rx1550nm 10km DOM BiDi SFP LC
    SFP-BX-D-101.25G Tx1550nm/Rx1310nm 10km DOM BiDi SFP LC
    SFP-2GBX-U-S202.5G Tx1310nm/Rx1550nm 20km DOM BiDi SFP SC
    SFP-2GBX-D-S202.5G Tx1550nm/Rx1310nm 20km DOM BiDi SFP SC
    SFP-B10G27-40BIDI SFP+40km, TX1270nm RX 1330 10G LC
    SFP-B10G33-40BIDI SFP+40km, TX1330nm RX1270 10G -LC
    CW-SFP10G-ZR47Duplex LC 10G 1470nm 80km CWDM SFP+,
    CW-SFP10G-ZR61Duplex LC 10G 1610nm 80km CWDM SFP+,
    DW-SFP10G-ZR57Duplex LC 10G C57 1531.90nm 80km DWDM SFP+,
    DW-SFP10G-ZR58Duplex LC 10G C58 1531.12nm 80km DWDM SFP+,
    SFP-10G-SRMultimode Dual LC 10G 850nm 300m SR SFP+
    XFP-10G-LRDual LC 10G 1310nm 20km LR XFP+
    SFP-10G-ERDual LC 10G 1550nm 40km ER SFP+
    SFP-10G-ZRDual LC 10G 1550nm 80km ZR SFP+
    SFP-10G-ZR100Dual LC 10G 1550nm 100km ZR SFP+
    CompatibleSFP/SFP+ Compatible Cisco ASR 1001-X 1002-X
    D-Link, Zyxel XGS-2210-28 and zyxel XGS-4600-32
    EPON OLT PX20+1.25G/1.25G Tx1490nm/Rx1310nm EPON OLT SFP PX20+
    Compatible Chinese OLT

    80km 10G SFP+ CWDM Transceiver Duplex LC With 1270 - 1610 Wavelength


    Description

    Linkopto’s LSPCXX92-3LCD80 CWDM Transceiver is a “Limiting module”, designed for 10GBASE-ZR, and 2G/4G/ 8G/10G Fiber- Channel applications.

    The transceiver consists of two sections: The transmitter section incorporates a EML laser. And the receiver section consists of a PIN photodiode integrated with a TIA. All modules satisfy class I laser safety requirements. Digital diagnostics functions are available via a 2-wire serial interface, as specified in SFF-8472, which allows real-time access to device operating parameters such as transceiver temperature, laser bias current, transmitted optical power, received optical power and transceiver supply voltage.

    Shipment
    International Express: DHL, FedEx,EMS,TNT, UPS and so on. It takes 3-7 days.

    Quality Control

    80km 10G SFP+ CWDM Transceiver Duplex LC With 1270 - 1610 Wavelength
