PN: LSB23X-3LCD40
10G SFP+ BIDI Module 10G BIDI SFP+ Tx1270/Rx1330nm 40km Compatible
with Cisco
Features
1. Supports 9.95Gb/s to 10.3Gb/s data rates
2. Simplex LC Connector Bi-Directional SFP+ Optical Transceiver
3. Single 3.3V Supply
4. Up to 40km on 9/125um SMF
A:1270nm DFB Laser transmitter,1330nm receiver
5. SFP+ MSA SFF-8431 Compliant
6. Digital Diagnostic SFF-8472 Compliant
7. RoHS compliant and Lead Free
8. Operating case temperature:
9. Standard: 0 ~ 70 °C
Applications
10GBASE-ER at 10.3125Gbps
10GBASE-LW at 9.953Gbps
Other Optical Links
10GBASE-BX
Standard
Ø SFP+ MSA Compliant
Ø SFF-8472 reversion 9.5 compliant
Ø IEEE802.3-2005 compliant
Ø Telcordia GR-468-CORE compliant
Ø FCC 47 CFR Part 15,Class B compliant
Ø FDA 21 CFR 1040.10 and 1040.11,class1 compliant
Ø RoHS compliant
Description
Linkopto's LSPB2392-3LCD40 series single mode transceiver is small
form factor pluggable module for duplex optical data communications
such as 10GBASE-LR/LW defined by IEEE 802.3ae. It is with the SFP+
20-pin connector to allow hot plug capability.
Linkopto's ESPB2392-3LCD40 module is designed for single mode fiber
and operates at a nominal wavelength of 1270nm; The transmitter
section uses a multiple quantum well DFB, which is class 1 laser
compliant according to International Safety Standard IEC-60825.
Linkopto's receiver section uses an integrated InGaAs detector
preamplifier (IDP) mounted in an optical header and a limiting
post-amplifier IC.
Guarantee
We promise all the advertised optical modules are brand new and
absolutely never use old and refurbished materials. All the optical
modules have been through functional test and aging test. We
provide 3 years warranty for all the optical transceivers from the
date of shipment.
Quality Control
FAQ
1. Do you have any MOQ?
Ans : No, we did not set any MOQ unless for Special promotion item.
2. How can I pay you?
Ans : We accept Bank Wire Transfer, Paypal ( for <$5000 payment
)
Please contact us for our Paypay account.
3. What is your warranty?
Ans : We offer basic 3 years warranty for all products.
4. Can I use your Transceiver module on Cisco or Alcatel-Lucent
equipment?
Ans : Yes, we can offer Transceiver modules compatible on Cisco,
Alcatel-Lucent, HP, Extreme…etc
5. How about your lead-time?
Ans : For normal order, we can deliver in 1~2 weeks, for Hot
selling products, we can deliver within 3 days
Related Products
| Item No. | Description |
|
| SFP-BX-U-10 | 1.25G Tx1310nm/Rx1550nm 10km DOM BiDi SFP LC |
| SFP-BX-D-10 | 1.25G Tx1550nm/Rx1310nm 10km DOM BiDi SFP LC |
| SFP-2GBX-U-S20 | 2.5G Tx1310nm/Rx1550nm 20km DOM BiDi SFP SC |
| SFP-2GBX-D-S20 | 2.5G Tx1550nm/Rx1310nm 20km DOM BiDi SFP SC |
| SFP-B10G27-40 | BIDI SFP+40km, TX1270nm RX 1330 10G LC |
| SFP-B10G33-40 | BIDI SFP+40km, TX1330nm RX1270 10G -LC |
| SFP-BX-U-S80 | 1.25G Tx1490nm/Rx1550nm 80km DOM BiDi SFP SC |
| SFP-BX-D-S80 | 1.25G Tx1550nm/Rx1490nm 80km DOM BiDi SFP SC |
| SFP-BX-U-L120 | 1.25G Tx1490nm/Rx1550nm 120km DOM BiDi SFP LC |
| SFP-BX-D-L120 | 1.25G Tx1550nm/Rx1490nm 120km DOM BiDi SFP LC |
| SFP-10G-SR | Multimode Dual LC 10G 850nm 300m SR SFP+ |
| XFP-10G-LR | Dual LC 10G 1310nm 20km LR XFP+ |
| SFP-10G-ER | Dual LC 10G 1550nm 40km ER SFP+ |
| SFP-10G-ZR | Dual LC 10G 1550nm 80km ZR SFP+ |
| SFP-10G-ZR100 | Dual LC 10G 1550nm 100km ZR SFP+ |
| Compatible | SFP/SFP+ Compatible Cisco ASR 1001-X 1002-X
Zyxel XGS-2210-28 and zyxel XGS-4600-32 |
| EPON OLT PX20+ | 1.25G/1.25G Tx1490nm/Rx1310nm EPON OLT SFP PX20+
Compatible Chinese OLT |
