PN: LS31X-3LCD40
10G SFP+ ER 1310nm 40km SM Duplex LC 10G-SFP-ERC Compatible with
Cisco
Description
The SFP+ 40KM module electrical interface is compliant to SFI
electrical specifications. The transmitter input and receiver
output impedance is 100 Ohms differential. Data lines are
internally AC coupled. The module provides differential termination
and reduce differential to common mode conversion for quality
signal termination and low EMI. SFI typically operates over 200 mm
of improved FR4 material or up to about 150mmof standard FR4 with
one connector.
Linkopto's LSP3192-3LCD40 1310nm DFB 10Gbps SFP+ transceiver is designed to transmit and
receive optical data over single mode optical fiber for link length
40KM.
Applications
1. 10GBASE-ER/EW 10G Ethernet
2. Other optical links
Features
Ø 10Gb/s serial optical interface compliant to 802.3ae 10GBASE-ER
Ø 1310nm DFB transmitter, PIN photo-detector
Ø Up to 40km transmission on SMF
Ø Duplex LC connector
Ø Metal enclosure, for lower EMI
Ø Electrical interface compliant to SFF-8431
Ø 2-wire interface for management
Ø Specifications compliant with SFF 8472
Ø Single 3.3V power supply
Ø Power dissipation < 1.5W
Ø Case operating temperature range: -5°C to 70°C
Standard
1. Compliant with SFF-8472 SFP+ MSA
2. Compliant to SFP+ SFF-8431 and SFF-8432
3. Compliant to 802.3ae 10GBASE-ER
4. RoHS Compliant
Specifications:
| P/N | SFP-10G-ER31 |
| Datarate | 10.3G/ps |
| Distance | 40KM |
| Wavelength | 1310nm |
| Transmitter | DFB |
| Receiver | PIN |
| Media | SMF |
| DDM/DOM | YES |
| Connector | LC |
| Application | 10 Gigabit Ethernet |
| Operating Temperature | 0℃~ +70℃ |
| Voltage Supply | 3.3V |
| Certification | CE/FCC/RoHS/TUV/UL |
| Brand | Neuter, OEM, Linkopto |
Relate Products
| Item No. | Description |
|
| SFP-BX-U-10 | 1.25G Tx1310nm/Rx1550nm 10km DOM BiDi SFP LC |
| SFP-BX-D-10 | 1.25G Tx1550nm/Rx1310nm 10km DOM BiDi SFP LC |
| SFP-2GBX-U-S20 | 2.5G Tx1310nm/Rx1550nm 20km DOM BiDi SFP SC |
| SFP-2GBX-D-S20 | 2.5G Tx1550nm/Rx1310nm 20km DOM BiDi SFP SC |
| SFP-B10G27-40 | BIDI SFP+40km, TX1270nm RX 1330 10G LC |
| SFP-B10G33-40 | BIDI SFP+40km, TX1330nm RX1270 10G -LC |
| CW-SFP10G-ZR47 | Duplex LC 10G 1470nm 80km CWDM SFP+, |
| CW-SFP10G-ZR61 | Duplex LC 10G 1610nm 80km CWDM SFP+, |
| DW-SFP10G-ZR57 | Duplex LC 10G C57 1531.90nm 80km DWDM SFP+, |
| DW-SFP10G-ZR58 | Duplex LC 10G C58 1531.12nm 80km DWDM SFP+, |
| SFP-10G-SR | Multimode Dual LC 10G 850nm 300m SR SFP+ |
| XFP-10G-LR | Dual LC 10G 1310nm 20km LR XFP+ |
| SFP-10G-ER | Dual LC 10G 1550nm 40km ER SFP+ |
| SFP-10G-ZR | Dual LC 10G 1550nm 80km ZR SFP+ |
| SFP-10G-ZR100 | Dual LC 10G 1550nm 100km ZR SFP+ |
| Compatible | SFP/SFP+ Compatible Cisco ASR 1001-X 1002-X
D-Link, Zyxel XGS-2210-28 and zyxel XGS-4600-32 |
| EPON OLT PX20+ | 1.25G/1.25G Tx1490nm/Rx1310nm EPON OLT SFP PX20+
Compatible Chinese OLT |
OEM and ODM
Linkopto accept OEM/ODM order
Shipment
International Express: DHL, FedEx,EMS,TNT, UPS and so on. It takes
3-7 working days.
Guarantee
We promise all the advertised optical modules are brand new and
absolutely never use old and refurbished materials. All the optical
modules have been through functional test and aging test. We
provide 3 years warranty for all the optical transceivers from the
date of shipment.
Quality Control
FAQ
1. Do you have any MOQ?
Ans : No, we did not set any MOQ unless for Special promotion item.
2. How can I pay you?
Ans : We accept Bank Wire Transfer, Paypal ( for <$5000 payment
)
Please contact us for our Paypay account.
3. What is your warranty?
Ans : We offer basic 3 years warranty for all products.
4. Can I use your Transceiver module on Cisco or Alcatel-Lucent
equipment?
Ans : Yes, we can offer Transceiver modules compatible on Cisco,
Alcatel-Lucent, HP, Extreme…etc
5. How about your lead-time?
Ans : For normal order, we can deliver in 1~2 weeks, for Hot
selling products, we can deliver within 3 days
