PN: EX2CxxX-3SCD80
10G X2 CWDM 1470~1610nm 80km SC GBIC Transceiver Compatible with
Cisco
Features
Ø X2 MSA Compliant
Ø 70-PIN connector
Ø SC duplex receptacle package
Ø Wavelength selectable to ITU-T standards covering CWDM grid
wavelengths
Ø Cooled EA-DFB/APD-PD
Ø Power supply: +5.0 V, +3.3 V, APS:+1.2 V
Ø Power Dissipation 4W Maximum
Ø Digital Diagnostic Monitoring
Ø Management and control with MDIO 2-wire bus
Ø XAUI electrical interface 4 x 3.125 Gb/s Ethernet
Ø ≤80km ER(Extended Range)10GBE
Ø RoHS compliant and lead free
Ø 0ºC to 70ºC Operating Case Temperature
Applications
Ø IEEE 802.3ae as 10GBASE-ZR
Ø X2 MSA Release3.0
Description
10Gb/s X2 transceiver module EX2CXX92-3SCD80 is a hot pluggable in
the Z-direction module that is usable in typical router line card
applications, Storage, IP network and LAN and compliant to X2 MSA.
The EX2CXX92-3SCD80 is a fully integrated 10.3Gbit/s optical
transceiver module that consists of a 10.3Gbit/s optical
transmitter and receiver, XAUI interface, Mux and De-mux with clock
and data recovery (CDR).This version of ETU-LINK Inc. transceiver
line uses an cooled CWDM EML Laser Diode to achieve 80km over
standard single mode fiber as 10GBASE-ZR of the IEEE 802.3ae.
Mechanical Dimensions:
Quality Control
Package
